576 MXL 025 Megadyne Isoran Timing Belt
- MXL
- 72 teeth
- 5.76″ pitch length
- 1/4″ wide
576 MXL 025 Megadyne Isoran Timing Belt is backordered and will ship as soon as it is back in stock.
Measuring Your Belt
Measuring Your Belt
Check the markings first. Most belts have their size printed on the back, for example A24, SPZ1000 or 8PK1200. Type that code into the search bar to find the exact match.
Markings worn off? Measure across the top of the belt for the width, and its depth. For the length, wrap a piece of string round the belt, mark where it meets, then lay the string flat and measure it.
Timing or ribbed belt? Count the teeth or ribs, and measure the gap between them.
Full step-by-step guide: How to measure your belt →
Still not sure? Call 020 8138 2848 and we’ll identify it for you.
Delivery and Shipping
Delivery and Shipping
We ship across the UK and worldwide. Choose an economical service if you can wait a few days, or express if the machine is stood still until the belt arrives. Delivery costs are worked out at checkout based on the weight of your order and where it's going. More Shipping Information
576 MXL 025 Megadyne Isoran Timing Belt
The Megadyne Isoran 576 MXL 025 is an MXL-profile imperial timing belt with a 2.032mm tooth pitch, a 5.76″ (146.3mm) pitch length, 72 teeth and a width of 1/4″ (6.3mm).
Megadyne Isoran imperial timing belts are made of polychloroprene rubber with a fibreglass tension cord and nylon fabric on the teeth. They’re maintenance-free, keep exact timing with no slip, and run from −25°C to 80°C.
Specification
| Brand and range | Megadyne Isoran |
|---|---|
| Profile | MXL |
| Tooth pitch | 2.032mm (0.080″) |
| Pitch length | 5.76″ (146.3mm) |
| Number of teeth | 72 |
| Width | 1/4″ (6.3mm) |
| Belt height | 1.14mm |
| Construction | Polychloroprene, fibreglass cord, nylon tooth facing |
Check it’s the right belt
- The old belt should be marked 576 MXL 025. 576 is the pitch length in hundredths of an inch, MXL is the profile, and 025 is the width in hundredths of an inch.
- If the marking has worn off, count the teeth: this belt has 72.
- MXL is an imperial pitch. It looks similar to metric T2.5 or 2GT but won’t mesh properly, so check your pulleys are MXL.
Not quite the right size? The nearest sizes in this width are 544 MXL 025 and 584 MXL 025. Not sure? Call 020 8138 2848 and we’ll help you find the right belt.
-
Section
-
Range
-
Construction
-
Height (mm)
-
Pitch / datum length (mm)
-
Pitch (mm)
-
Belt width (mm)
-
Teeth
