8PJ685 MEGADYNE PV Rubber Ribbed Belt
8PJ685 MEGADYNE PV Rubber Ribbed Belt is backordered and will ship as soon as it is back in stock.
Measuring Your Belt
Measuring Your Belt
Check the markings first. Most belts have their size printed on the back, for example A24, SPZ1000 or 8PK1200. Type that code into the search bar to find the exact match.
Markings worn off? Measure across the top of the belt for the width, and its depth. For the length, wrap a piece of string round the belt, mark where it meets, then lay the string flat and measure it.
Timing or ribbed belt? Count the teeth or ribs, and measure the gap between them.
Full step-by-step guide: How to measure your belt →
Still not sure? Call 020 8138 2848 and we’ll identify it for you.
Delivery and Shipping
Delivery and Shipping
We ship across the UK and worldwide. Choose an economical service if you can wait a few days, or express if the machine is stood still until the belt arrives. Delivery costs are worked out at checkout based on the weight of your order and where it's going. More Shipping Information
8PJ685 MEGADYNE PV Rubber Ribbed Belt
8PJ685 MEGADYNE PV Rubber Ribbed Belt
Megadyne manufactures J, L and M section multi-rib V belts for use in high speed and high ratio drive applications. Constructed with polybutadiene rubber and polyester cords, our belt flexes around small drive pulleys allowing for high ratio drives to be used in compact drive package design. Multi-V Rib belts run quiet and deliver low vibration and will not turnover at high speeds. Fabric is added to the belts back side to increase lateral stiffness.
In addition to use in power transmission applications like machine tools, compressors, commercial appliances and fitness equipment, rubber multi V Rib belts are commonly covered would high friction, wear resistant rubber for use in applications like puller belts in extrusion applications.
Multi-Rib V-belts conform to ARPM Engineering Standard IP-26 and ISO 9982. Multi-Rib V-belts are specified by the effective length in inches multiplied by 10, the cross-section and the number of ribs – Example: 445J6, where 44.5” is the belt length, J is the pitch and the number of ribs is 6.
