SPC 1250 x 4 Groove Taper Lock Pulley - 5040 Bush
SPC 1250 x 4 Groove Taper Lock Pulley - 5040 Bush is backordered and will ship as soon as it is back in stock.
The SPC1250/4 is a 4-groove SPC taper lock pulley with a 1250mm pitch diameter. It runs SPC wedge belts and C (22mm) classical V-belts.
It takes a 5040 taper lock bush, which takes shafts from 70mm to 125mm in standard metric bores. The bush is sold separately: choose a 5040 bush in your shaft size and the pulley can be fitted and removed without machining.
It’s made from cast iron (EN-GJL-200) with grooves to ISO 4183 and DIN 2211, black phosphated against corrosion, and statically balanced for belt speeds up to 35m/s.
Specification
| Part number | SPC1250/4 |
|---|---|
| Groove section | SPC (belt top width 22mm) |
| Number of grooves | 4 |
| Pitch diameter | 1250mm |
| Outside diameter | about 1259.6mm |
| Face width | about 110.5mm |
| Bush size | 5040 taper lock (sold separately) |
| Shaft range | 70mm to 125mm with a metric 5040 bush |
| Material | Cast iron EN-GJL-200, black phosphated |
Check it’s the right pulley
- The old pulley should be marked SPC1250/4 or SPC 1250 x 4, and the bush 5040.
- Measure across the outside of the rim: about 1259.6mm. The pitch diameter is smaller because it’s measured where the belt sits in the groove.
- Check your belts are SPC (or the matching classical section) and you need 4 grooves.
Not quite the right size? The nearest diameter with 4 grooves is SPC1000/4. Not sure? Call 020 8138 2848 and we’ll help you find the right pulley.
-
